Matambo anoshandiswa muzvinhu zvakakosha zvemotokari senge bhatiri inotungamira uye injini yekamuri wiring inofanirwa kupa kupisa kwakanyanya, kuchinjika uye kuramba kwemakemikari kusangana nezvinodiwa zvemazuva ano emagetsi emagetsi masisitimu. TheFL2G Silicone Rubber Automotive Cablechimwe chezvakanakisa zvigadzirwa zveGerman standard mota tambo nekuda kweyakasarudzika mabhenefiti esilicone rubber insulation. PVC kana kuti cross-yakabatanidzwa polyethylene (XLPE) waya dzakavharirwa dzinoita kuchembera, kuoma uye kutotsemuka pasi penguva yakareba-yetembiricha yepamusoro, kusvibiswa kwemafuta uye kuzunguzika.
Chii chinonzi FL2G Silicone Rubber Automotive Cable?
FL2G Silicone Rubber Automotive Cableis one-core, silicone rabha{1}}insulated low-voltage automotive cable inofambirana neISO 6722 standard.Mavakirwo ayo ndeaya anotevera:
-
Conductor: Cu-ETP1 isina kana mhangura yakanamirwa, inofambirana nezviyero zveDIN; stranded kuvaka inovimbisa kuchinjika kwakanyanya.
-
Insulation: Silicone rabha
-
Tembiricha yekushanda: Kuenderera mberi kwetembiricha yekushisa ye -40 dhigirii kusvika +200 dhigirii (zvimwe zvinoratidza kupikisa maawa 3,000 ekuchembera kwakanyanya).
-
Humwe hunhu: Halogen-yemahara (inoenderana neIEC 60754-1); inopesana nemafuta, mafuta, acids, alkalis, brake fluid, uye mamwe organic media; inochengetedza kuchinjika kwakanakisa pane tembiricha yakaderera.
-
Common cross-zvikamu zvinotangira pa0.5 mm² kusvika 70 mm² (fekitari yedu inogona kugadzira kusvika 120 mm²); inowanikwa mumarudzi akasiyana-siyana (tsvuku, dema, bhuruu, yero, grey, brown, chena, yepepuru, yegirini, yakasikwa, nezvimwewo) kuti zvizivikanwe zviri nyore.
Tafura iri pazasi inodonongodza tekinoroji yemamwe mamodheru akajairika:
|
Nominal cross{0}section (mm²) |
Conductor Construction (Nhamba yeStrands / Strand Diameter) |
Maximum conductor dhayamita (mm) |
Kunyanya kuramba pa20℃(Ω/km) |
Nominal insulation ukobvu (mm) |
Kunze kwedhayamita renji (mm) |
Approx. uremu (kg/km) |
| 0.5 | 16/0.21 | 1.1 | 37.1 | 0.48 | 2.0–2.3 | 8 |
| 1.5 | 30/0.26 | 1.8 | 12.7 | 0.48 | 2.7–3.0 | 17.9 |
| 2.5 | 50/0.26 | 2.2 | 7.6 | 0.56 | 3.3–3.6 | 29.5 |
| 6 | 84/0.31 | 3.4 | 3.14 | 0.64 | 4.6–5.0 | 66 |
| 16 | 126/0.41 | 6.3 | 1.16 | 0.8 | 7.7–8.3 | 173 |
| 35 | 276/0.41 | 9 | 0.527 | 1.04 | 10.4–11.0 | 361 |
| 70 | 360/0.51 | 12.5 | 0.259 | 1.25 | 14.2–15.5 | 750 |
Aya ma paramita anoratidza kuti FL2G Silicone Rubber Automotive Cable inosanganisa magetsi mashoma uye simba remuchina rakakwirira nedhayamita diki rekunze, zvichiita kuti ikwane tambo dzemotokari munzvimbo{1}}zvisina kuvharirwa.
Kubatsira Kwakakosha uye Kuenzanisa
Kana ichienzaniswa netambo dzemotokari dzenguva dzose, FL2G silicone rabha yemotokari tambo inomira zvakanaka nekuda kwekukwirisa kwayo-kuramba tembiricha uye kudzika-kusanduka kwe tembiricha:
·Zvichienzaniswa nePVC-tambo dze insulated (dzakadai seFLRY): PVC cables hadzidhure uye dzakakodzera kune-cabin circuits, asi tembiricha yenguva refu-ino shanda inongogumira ku -40℃kusvika +105℃or +125℃; munzvimbo dzinopisa zvikuru dzekamuri yejini, dzinowanzopfava, kuremara kana kuchembera nguva isati yakwana.FL2G, zvakasiyana, inoshingirira tembiricha inoramba ichikwira kusvika 200 degrees , izvo zvinoita kuti ive sarudzo iri nani kunzvimbo dzinopisa-pamusoro peinjini, exhaust system, kana materminal positive ebhatiri.
·Tichienzanisa nekuyambuka-yakabatana polyethylene kana kuchinjika-tambo dzepololefin dzakabatanidzwa: Tambo idzi dzine simba remuchina uye rinoramba tembiricha inosvika madhigirii 150, asi kazhinji hadzina kuchinjika zvakanaka kana zvichienzaniswa nerabha yesilicone. Silicone rabha inochinjika pa -40 dhigirii saka kashoma kutsemuka panguva yekuiswa kana painozunguzika.
·Iyo FL2G silicone rabha yemotokari tambo yakagadziridzwa seyemotokari bhatiri inotungamira mukuenzanisa nedzimwe silicone rabha tambo. Inoenderana neyakaomesesa ISO 6722 Kirasi F zviyero. Kupokana kwayo kwemakemikari kwakagadzirirwa nharaunda yemotokari (kuratidzwa kumafuta, brake fluid, nezvimwewo).
FL2G silicone rabha yemotokari tambo yakagadzirirwa kushanda zvakanaka munzvimbo dzakaomarara, ine tembiricha yakakwira uye makemikari kuramba, kuzunguzika uye kuchinjika pakudziya kwakaderera. Mutengo payuniti wakakwira kupfuura iwo weyakajairwa PVC tambo, asi inoderedza zvakanyanya mwero wekutadza uye mutengo wekutsiva nekuda kwekuchembera kwekudzivirira.
Yakajairika Yekushandisa Mienzaniso yeFL2G Silicone Rubber Automotive Cable
FL2G silicone rubber automotive cable inonyanya kushandiswa kutungamirira mabhatiri akanaka neasina kunaka, wiring munzvimbo dzakakwirira-injini yetembiricha, masekete ari pedyo nekufambiswa, uye magetsi anoda kuchinjika zvakanyanya. Vagadziri vakawanda vanonyatso tsanangura kukodzera kwayo kushandiswa se "battery lead-waya dzemotokari" uye mu"makombi einjini."
Muenzaniso Chidzidzo 1:Kugadziriswa kweBattery Leads muHigh-Temperature Engine Compartments
Mugadziri wemotokari dzinotakura vanhu akamboshandisa tambo dzebhatiri dzePVC munzvimbo dzeinjini uko tembiricha yaiwanzopfuura 150 degrees. Mushure memakore maviri kusvika matatu ekushandiswa, iyo insulation yakaomeswa uye yakatsemuka, zvichikonzera kusabatana kwakashata uye kunyangwe njodzi yemapfupi maseketi. Pakuchinja kuenda kuFL2G silicone rabha tambo, kushanda kwe insulation kwakaramba kwakagadzikana kuburikidza ne-tembiricha yekuchembera uye nemiyedzo chaiyo-yemotokari yemumugwagwa (kusanganisira-yenguva yakareba-kupisa kwekushisa). Matambo aitamba zvakanaka panguva yaitonhora-mamiriro ekutanga, zvichideredza nyaya dzemagungano uye kuzunguzika{10}}kukonzerwa nekuneta kunokonzerwa netambo dzakaoma dzetambo. Maapplication akafanana ava kujairika kune{12}zvino bhatiri rinotungamira mumhando dzakasiyana siyana dzeGerman neJapan.
Muenzaniso Chidzidzo 2:Kuvimbika Kuvandudzwa kweMotokari dzeKutengesera uye Kuvaka
Marori-anorema ebasa nemichina yekuvaka anoshanda munzvimbo dzakatonyanya kuomarara dzeinjini dzinoonekwa nekusvibiswa kweoiri, kuzunguzika, uye kudzikama kwakanyanya. Vashandisi vakataura nezvekuwedzera kunoshamisa kwehupenyu hwehupenyu hwemawaya mushure mekutsiva tambo dzemhando yepamusoro-dzetembiricha neFL2G, zvichiita kuti kuderedzwa kuderedzwa kunokonzerwa nekukundikana kwemagetsi nekuda kwekuparara kwekudzivirira. Kupokana kwakanakisa kwesilicone rabha kubhureki fluid uye mafuta kwakadzikisawo njodzi yekuora kwemakemikari.
Muenzaniso Chidzidzo 3:Zvakawedzerwa Zvishandiso muMotokari dzeMagetsi neHybrid
Kunyange zvazvo FL2G yagara ichishandiswa mu12V/24V low-voltage masisitimu, -tembiricha isingaite yakwezva kufarira kuti ishandiswe mune yakaderera-masaini emagetsi kana tambo dzemagetsi ekuwedzera-kunyanya pamabhatiri pack uye pedyo nemagetsi emagetsi{7}mune dzimwe mota dzemagetsi. Halogen -yemahara masikirwo ayo anoita kuti ive yakakodzera kune maapplication ane kuomarara kwezvakatipoteredza nekuchengetedza zvinodiwa.
Mhosva idzi hadzisi zviitiko zvega asi dzinobva kune yakasikwa makemikari kugadzikana uye emuviri zvimiro zvesilicone rubber: kusiyana nePVC, haibudisi magasi anokuvadza kana kushatisa nekukurumidza pakupisa kwakanyanya, panguva imwe chete ichichengetedza elasticity kuti inyatso kunzva kudengenyeka kwemotokari.
Sarudzo uye Kufunga Kwekushandisa
Pakusarudza chigadzirwa, tarisa pakufananidza chinjikira-chikamu chine mutoro uripo, mhando yekondakita (share isina chinhu maringe nemhangura yakabikwa{2}ine tinned inopa kusimba kwecorrosion resistance), coding yeruvara, uye chero zvitupa zvinodiwa. Panguva yekuisa, dzivisa kutambanudza zvakanyanya kana kuputika pamusoro pemicheto yakapinza; nepo silicone rabha ichipisa-inodzivirirwa, dziviriro kubva pamikwenya inotsamira panzira dzakakodzera dzekufambisa. Dzivisa kuratidzwa kwenguva refu kune yakanyanya UV mwaranzi kana yakanyanyisa makemikari nharaunda panguva yekuchengetedza uye yekufambisa.
Isu tinopa yakazara chigadzirwa renji kubva pa0.35 mm² kusvika 120 mm². Sarudzo dzekugadzirisa dzehurefu, ruvara, uye kurongedza (semuenzaniso, reels, zvigubhu) zviripo kuti zvizadzise zvinodiwa zveese maOEM uye mushure memusika.
Summary
Inosanganisira silicone rabha insulation, iyo FL2G silicone rabha yemotokari tambo isarudzo yakavimbika kune mota inotungamira mabhatiri uye yakakwirira-tembiricha yejini wiring, nekuda kwehupamhi hwekushanda kwayo tembiricha (-40 madhigirii kusvika +200 madhigirii ), kusamira kwemakemikari kwakanaka, uye kuchinjika pakudziya kwakadzikira. Kuenzaniswa nemhando dzetambo dzakajairwa sePVC neXLPE, inopa kugadzikana kwepamusoro kwenguva refu pasi pemamiriro ekushanda akanyanya; nepo mutengo wekutanga wakakwira zvishoma, unonyatso dzikisa mitengo yekutadza uye mari yekugadzirisa. Kubva kumota dzevatyairi kuenda kumotokari dzekutengesa, uye kubva kune yechinyakare mukati memoto injini dzemoto kusarudza mashandisirwo emagetsi matsva,FL2G silicone rabha yemotokari tambos chinyararire chengetedza kuchengetedzwa uye kuvimbika kwemotokari yemagetsi masisitimu.
Kana uri kusarudza-tambo dzemotokari dzetembiricha dzepamusoro kana kudzoreredza tambo dzewaya dziripo, zvinokurudzirwa kukoshesa ISO 6722 mwero uye kukumbira madatabase ezvino uye magwaro ezvitupa kubva kune vanotengesa vanozivikanwa. Iyo tambo yekurudyi kazhinji ndiyo inonyanya kukosha asi yakakosha link mukuona kuvimbika kwesystem.
